745 SQ.FT ECO – 915 sq ft Tiny House Home – $81,900 – Jersey City, NJ

MASS TIMBER PRODUCT

CROSS-LAMINATED TIMBER (CLT) HOUSE KIT

A WOOD PANEL SYSTEM HOUSE, MODEL # CLT-85_CHALET, sold exclusively by ECOHOUSEMART and custom made to order. It is made of today's most advanced Mass WOOD technology CROSS-LAMINATED TIMBER PANELS (CLT), species - white Spruce.

The Solid cross-laminated timber panels (CLT) and the other (described below building materials) are delivered to the construction site for local professional assembly by construction companies using a boom crane within the shortest possible construction period. CLT wall set is assembled within a day. WOOD panels can be used as a load-bearing structure and an interior finish material.

Construction with solid timber elements optimizes the inherent structural behavior of wood, creating a more homogeneous structural product. As mass wood products, these building materials are manufactured from an entirely renewable resource that, when compared with steel and concrete counterparts, has the capacity to sequester carbon in the structure of buildings and to reduce the negative environmental impact of construction on the planet.

CROOS-LAMINATED HOUSE BUILDING PHYSICS:

• The CLT wall systems are naturally breathable, which, integrated with appropriate mechanical systems, will result in a healthy indoor environment that maximizes occupant comfort and health
• Wood mass: comfortable living environment, heat storage in winter, insulation in summer
• Visual quality: pleasantly warm wood surfaces, nature in architecture, outstanding constructional properties
• Air tightness – or more accurately referred to as convection tightness – is an essential parameter of modern CLT houses and sustainable constructions.
• Very good thermal insulation and heat protection
• Passive house and low-energy house standards can be optimally achieved
• Healthy and comfortable indoor climate, optimal heat storage capacity, and humidity regulation
• Recommended in terms of building biology
• High fire resistance

MODEL: CLT-85_CHALET

THIS CROSS-LAMINATED TIMBER HOUSE KIT IS NOT BUILT YET AND WILL BE CUSTOM ORDERED ACCORDING TO YOUR REQUIREMENTS. ORDERS TAKE GENERALLY UP TO 150 DAYS TO RECEIVE.

A genuine ECOHOUSEMART Mass WOOD house provides a healthy living environment, high indoor air quality, and a warm, stress-reducing atmosphere. It's an ecological home that quite literally takes good care of the people within its walls.

PRODUCT OVERVIEW OF THE CLT-85_CHALET PREFAB KIT:

• Design: MODERN CHALET
• Floors: 1
• Gross Area: 915 sq.ft, Total area of the house including terrace
• Net area (inside, living area of the house): 745 sq.ft
• Bedrooms: 3 (could be combined upon requirement)
• Bathrooms: 1


ECOHOUSEMART “CLT-85_CHALET” PREFAB WOOD PANEL HOUSE KIT INCLUDES THE FOLLOWING SYSTEM MATERIALS ONLY (ITEMS 1-7 BELOW):

1. Design:

• Preliminary architectural drawings (unstamped)
• Shop Structural Drawings (unstamped)
• Assembly diagram

2. Cross-laminated timber wall set:

• A set of CROSS-LAMINATED WALL PANELS (CLT) for load-bearing external and internal walls - 4 2/3” (120mm), pre-cut according to the project documentation, finished quality from inside in wood natural color (non painted or stained), industrial quality on the outside (requires finishing)

3. Additional structural elements:

• Sill plate - underlying board to install panels onto the foundation - 1 5/8" х 4 2/3” (41mm x 120mm)
• Interior partition walls framing - 1 5/8" х 4” (41mm x 100mm)

4. Roofing*

• Inner ventilation battens – sawn board 1” x 2” (25mm x 50mm)
• Vapor barrier and vapor diffusion membrane
• Framing board for rafters roof system - 1 5/8" х 8” (41mm x 200mm)
• Counter battens, (spruce) vertical - 1 2/3” x 2” (44mm x 50mm)
• Battens, (spruce) horizontal, - ¾” x 4 ¾” (20mm x 120mm)

5. Outdoor finishing materials:

• Facade subsystem board (41mm x 100mm)
• Ventilation battens (44mm x 50mm) for external facades
• Weather ventilated boarding, veneer for cladding of external walls - white Spruce, T&G ¾” x 7” (19 x 177mm)
• Terrace board, white Spruce, 1 2/3" x 4 3/4" (41 x 120mm)

6. Interior finishing materials

• Veneer for cladding of internal framed walls - white Spruce, T&G ¾” x 7” (19 x 177mm)
• T&G ceiling board, white Spruce 3/4" x 4 3/4" (20 x 121 mm)
• Casing board for windows and doors - planed board 3/4" x 4" (20 x 100mm)
• T&G floor board 1,5″ thick. Species – white Spruce, engineered
• Plinth 1,2" x 1,6"

7. Set of fasteners:

• ECOHOUSEMART will source and ship fasteners and connection hardware only for CLT panels. ECOHOUSEMART typically sources all fasteners required for CLT-to-CLT connections and CLT-to-structural framework. Fasteners used for other building materials, or that are not part of the direct load path of the CLT, are usually not included.

ATTENTION!

WE DO NOT SUPPLY ANY OTHER MATERIALS WITH THE ADVERTISED “CLT-85_CHALET” KIT IN THIS OFFER!

OFFERED SEPARATELY:

• Windows and door package is available at additional cost. European style double or triple glazed, white VINYL or any color wood clad, tilt and turn windows at additional cost. Please contact us for more details.
• Drilling holes for concealed wiring.
• *CLT roof panels instead of a roof rafter system are available at an additional cost.
• SASHCO coatings and finishes materials. Coatings and finishes should be applied once the building has been enclosed and the CLT has reached moisture equilibrium.
• Roof covering materials (Soft shingles, OSB sheathing, Roll waterproofing, Vapor barrier and vapor diffusion membrane)
• It is possible to modify the package contents, available upon request. Subject to price adjustment.
• Stamp over the Shop Structural Drawings

IF THIS LISTING IS NOT EXACTLY WHAT YOU REQUIRE, PLEASE CONTACT US FOR A PERSONAL EBAY LISTING FOR YOUR EXACT REQUIREMENTS!

CROSS-LAMINATED TIMBER (CLT) PRODUCT ADVANTAGES

A distinctive feature of the proposed CLT structure is factory readiness. All CLT panels are made exactly according to the project using advanced CNC woodworking machinery and delivered completely ready for assembly. This allows you to save time and money: you get a technologically advanced solution and fairly simple process of assembly. Construction is easy and fast. The kit can be erected by a small crew within a week's time. CLT panel lifting equipment is required.

When compared to related technologies of construction (concrete, masonry, beams, frame houses), CLT panel technology stands out clear competitive advantages:

Structural

• Highly load-bearing building material
• Multiple crossed and glued lamellae offer excellent dimensional stability and size accuracy
• Outstanding static properties, high seismic resistance
• Enables modern architectural shapes due to loads being transferred in two directions
• CLT system is structurally comparable to steel and concrete but six times lighter than concrete

Product-specific

• Quality-controlled production, continuous internal and external checks
• Industrially prefabricated construction elements thanks to CNC timber framing according to plan
• The ideal building material for adding storeys due to its specific weight

Planning

• High dimensional accuracy due to CNC timber framing
• Planning freedom and free floor plans
• No limits on individual forms of expression in modern timber construction architecture
• More space, relatively small component thicknesses are possible, creating an economic ratio of gross to net floor area.
• The ability of exterior panels to be comparable with many facing materials (brick, stone, any siding materials, etc.) makes the technology versatile and adaptable to any architectural style.

Ecological

• An ecological building material made of renewable raw material
• The durable construction method that retains its value
• A building product that stores CO2 and produces fewer greenhouse gas emissions during manufacture
• Highly efficient production with low primary energy demand
• The wood fiber used in CLT is traceable from certified forests
• 100% environmentally friendly, including the adhesive system

Time-related

• Ready-to-assemble trimmed panel components under weather-protected conditions are delivered directly to the construction site.
• Large format components minimize the assembly time and hence the construction costs.
• Dry construction method, hence rapid erection and soon ready for occupancy
• Assembly-friendly
• In comparison to concrete structures, CLT projects are installed in a shorter period of time due to the nature of prefabrication and dry materials. This is a crucial advantage, particularly in multi-story buildings.
• Detailed pre-construction planning can help to ensure the installation of CLT is easy, safe, and efficient. Many erectors install up to 14,000 sq. feet per day with a team of 4-6 people.

Fire resistant

• Fire resistance refers to the time during which building elements are able to continue performing their functions despite the presence of a fire. The burning rate of wood structural elements depends on the  thickness of CLT panels, the moisture content, and the amount of exposure to fire. Due to its mass, CLT panels char slowly. Once charred, combustion slows and eventually stops. CLT assemblies also have fewer concealed spaces, which reduces a fire’s ability to spread undetected. CLT structures suffer less degradation than concrete and steel structures in a catastrophic fire event.

Seismic resilience

• Because of their dimensional stability and rigidity, CLT panels create an effective lateral load resisting system. Researchers have conducted extensive seismic testing on CLT and found panels to perform exceptionally well with no residual deformation, particularly in multi-story applications. In Japan, for example, a seven-story CLT building was tested on the world’s largest shake table. It survived 14 consecutive seismic events with almost no damage. CLT also offers good ductile behavior and energy dissipation.

Cost efficient

• Cost efficiencies are achieved through the combination of material and installation costs, and the associated benefits of using a prefabricated system that is structural and architectural

NOTES:

• MANUFACTURING IS CUSTOM, AND ORDERS TAKE GENERALLY UP TO 150 DAYS TO RECEIVE SINCE THE CUSTOMER APPROVES THE STRUCTURAL DRAWINGS.
• THIS CLT HOUSE KIT IS MADE OF HIGH-QUALITY NORTHERN WHITE SPRUCE, EASY PROFESSIONAL ASSEMBLY TO BE ORGANAIZED BY BUYER.
• YOU ARE BUYING ONLY THE PREFABRICATED CLT KIT NON PAINTED, OR STAINED, IN WOOD NATURAL COLOR. PLEASE READ ABOVE WHAT IS INCLUDED IN THE KIT. NO LABOR OR ANY OTHER MATERIALS EXCEPT SPECIFIED ABOVE ARE INCLUDED!
• THIS KIT DOES NOT INCLUDE WINDOWS, DOORS, PLUMBING, ELECTRICAL, FIXTURES SUCH AS TOILETS SINKS OR CABINETS.
• CONCRETE, ERECTION, INTERIOR FINISHING, ROOF INSULATION, STAIRWAY, PLUMBING, HVAC, ELECTRICAL ARE TO BE PAID BY BUYER SEPARATELY TO LOCAL SUPPLIERS.
• ALL PERMITS AND RELATED FEES ARE PURCHASER’S RESPONSIBILITY.
• THE BUYER IS RESPONSIBLE TO MEET THE BUILDING PERMITS AND REQUIREMENTS IN THEIR STATE/COUNTY. SO PLEASE CHECK AT YOUR COUNTY BUILDING DEPARTMENT OFFICE TO FIND OUT WHAT IS REQUIRED.
• CUSTOMERS AGREE TO HOLD ECOHOUSEMART AND ANY AUTHORIZED DEALERS FREE OF ANY LIABILITY FOR IMPROPER INSTALLATION, MAINTENANCE, AND REPAIR OF ANY ECOHOUSEMART PRODUCTS.
• PAYMENT: BY PAYPAL UNLESS OTHER ARRANGEMENTS ARE MADE PRIOR TO PURCHASE.
• HOUSE KIT MANUFACTURING WILL NOT BEGIN UNTIL THE FULL PAYMENT CONDITIONS ARE MET.
• CONSTRUCTION COMPONENTS DIRECTLY EXPOSED TO WEATHERING MUST BE FACED WITH EFFECTIVE WEATHER PROTECTION.
• SHIPPING: FREIGHT WILL BE PAID BY THE SELLER.
• UNLOADING FROM SHIPPING CONTAINER IS NOT INCLUDED IN PRICE AND WILL BE PAID BY BUYER TO LOCAL AGENTS / SPECIALISTS.
• YOU CAN ARRANGE YOUR OWN PICK UP FROM THE WAREHOUSE IN JERSEY CITY, NJ 07305
• WE WILL BE GLAD TO GIVE YOU A FREE PRICE QUOTE ON YOUR CUSTOM HOUSE INQUIRY.

PRIOR TO PURCHASE:

• Construction experience is required to assemble this building package. It is recommended that a professional contractor be hired to install the kit if the purchaser is not qualified.
• Check with your local building official or Code Enforcement Office to obtain necessary permits and review possible site zoning, foundation, and building requirements or restrictions (including, but not limited to: frost depth, soil-bearing pressure, drainage, etc.).
• Ensure that the building requirements meet the specifications of the CLT building package kit (wind, seismic, snow load, exposure, etc.).
• In some cases, engineering criteria required for your build site may warrant a building plan different from the standard.
• ECOHOUSEMART will work with your licensed local architect to provide a suitable solution for your zoning requirements.

LOGISTICS AND PACKAGING:

• The elements are delivered directly to the construction site in a container for self-collection. Unloading from shipping container is not included in price and will be paid by buyer to local agents / specialists.
• Our products are well shop-packed, which ensures the preservation of details during loading and unloading, transportation.
• The transportation package is compiled of details of the same section area and length.

AT ECOHOUSEMART WE WILL CUSTOMIZE OUR KITS TO FIT YOUR INDIVIDUAL PLANS, WISHES, AND DREAMS.

WE ARE LOOKING FOR TALENTED DESIGNERS, BUILDERS AND NEW DEALERS THROUGHOUT THE US.

LOOKING FORWARD TO HEARING FROM YOU, AND HAVE A GREAT DAY!

ECOHOUSEMART
